IP69K STAINLESS STEEL MOTOR -
TENV
Huifeng’s IP69K stainless steel motor is designed for food processing, pharmaceutical and other applications requiring extreme cleanliness and frequent washdowns.
- TENV
- 2, 4, 6 poles
- 0.06 – 1.5kW
- IEC frame 56 – 90
- NEMA frame 56C
1989
成立时间
500+
员工
30
工程师
55
专利数
130,000
公司面积
170+
检验项目
20
世界知名客户
500+
十分满意客户
Stainless Steel IP69K Motor: Built Tough & Clean
Huifeng’s stainless steel washdown motors are designed for demanding environments. Made with high-grade 304 & 316L stainless steel, they resist corrosion and last longer. Perfect for food, beverage, and pharmaceutical industries.
Why Choose Huifeng's Stainless Steel IP69K Motor
- IP69K Rated – Withstands high-pressure, high-temperature washdowns.
- TENV Construction – Totally Enclosed, o blades or fan cover, no places to trap dirt.
- Large Junction Box – Easy wiring access and maintenance.
- Laser-Engraved Nameplate – Permanent, clear labels for traceability.
- Smooth Surface – No crevices; easy to clean and sanitize.
- Inverter Duty Operation – Runs smoothly on VFDs:
- 4:1 Constant Torque (CT)
- 10:1 Variable Torque (VT)
- Hygienic Cable Gland – EHEDG-certified for sanitary safety.
- Low motor surface temperature – Thanks to the low losses electromagnetic design and excellent process, the surface temperature of motor is low enough, nobody will be scalded by the hot motor
产品范围
- 效率： IE4
- 功率范围： from 0.06kW to 1.5kW
- 极数： 2, 4, 6 poles
- 电压范围： 110V - 690V
- 绝缘等级： F
- IP等级 IP69K
- 机座号：
- IEC: 56-90
- NEMA: 56C
- 相数： 三相
- 机壳材质： 304, 316L
- Enclosure: TENV
- Certificate: CE, CSA
What's the Cooling Principle of Huifeng's TENV Stainless Steel IP69K Motors
TENV (Totally Enclosed Non-Ventilated) motors rely on passive heat dissipation through the motor’s external surfaces. Unlike TEFC (Totally Enclosed Fan Cooled) motors, they have no cooling fan or vents, making them ideal for dirty/wet environments.
How It Works
Internal Heat Transfer
Copper windings transfer heat to the frame via direct metal-to-metal contact.
External Heat Dissipation
The enlarged housing acts as a “heat sink” – heat radiates naturally to ambient air.
In Huifeng stainless steel motors:
→Stainless steel doesn’t conduct heat well. To keep our motors cooler, Huifeng uses the low losses electromagnetic design and excellent process that create less heat.
→ Lack of fan/fan cover eliminates dust traps, improving thermal uniformity.
The Difference Between TENV & TEFC in Washdown Zones
Factor | TENV Motor | TEFC Motor |
|---|---|---|
Cooling Method | Natural convection (no moving parts) | Forced air (external fan) |
Dirt Accumulation | Zero risk (sealed surfaces) | Fan shroud traps debris |
Hygiene | Smooth surfaces survive caustic wash | Fan blades corrode/contaminate |
Motor Power | Usually no more than 1.5kW(2hp) | The max power of Huifeng's TEFC motor is 4kW(5hp) |
Motor Size | Totally round body with compact size | With a welded terminal box, size is bigger |
Real-World Example: Dairy Processing Plant
A TEFC motor failed every 6 months:
❌ Fan blades clogged with cheese residue → Overheated → Burned windings.Switched to Huifeng’s stainless steel TENV motor:
✅ No fan = nothing to clog.
✅ Survived 2+ years of daily 80°C NaOH washdowns.
daf
工厂视频
走近惠丰
As a leading Chinese manufacturer of electric motors and 永磁电机 since 1989. Its products are mainly sold in Europe, North America, and Australia.
优质的电机 = 更少的更换 = 更少的停机维护时间
使用我们的电机，您可以花国产的价格买到欧洲品质的电机。
看看我们的客户怎么说
惠丰是不同的。他真的知道我们需要什么，完全按照我们的需求来设计电机并且解决我们的疑惑。
Jemma Stone
我们已经和惠丰合作了很多年，惠丰的电机从来都没有质量问题。
Kelly Joe
我的一个客人告诉我，他20年前和我们买了一台惠丰生产的电机，现在这台电机仍然在运转！
Samantha Gilbert
认证
CE(Intertek)
CSA(CSA Group)
CCC(CQC)
ISO9001
常见问答
How can the motor cooled down without a motor fan?
TENV motor relys on passive heat dissipation through heat transfer from copper windings to the motor frame via direct metal-to-metal contact.
When designing motors, Huifeng uses more materials to lower the temperature rise of the motors, allowing the motors to achieve thermal balance simply by dissipating heat on the surface of the frame.
Can you make IE3 IP69K motor ?
Yes, we have IE3 IP69K stainless steel motor.
What's IP69k
Dust ingress (“6” = Dust-tight)
High-pressure, high-temperature water jets (“9K” = Resists close-range washdowns with 80°C+ water)
Do you have IP68 motor?
No, IP68 is submersible motor, our motor can not be used under water.
